ITEM |
UNIT |
X5040 |
X5032 |
|
Table size |
mm |
400*1700 |
320*1325 |
|
T-slots（NO./Width/Pitch) |
|
3/18/90 |
3/18/70 |
|
Longitudinal travel(manual/auto) |
mm |
900/880 |
700/680 |
|
Cross travel(manual/auto) |
mm |
315/300 |
255/240 |
|
Vertical travel(manual/auto) |
mm |
385/365 |
350/380 |
|
Rapid feed speed |
mm/min |
2300/1540/770 |
2300/1540/770 |
|
Max load |
kg |
800 |
600 |
|
Spindle taper |
|
7:24 ISO50 |
7:24 ISO50 |
|
Spindle speed range |
r/min |
30~1500 |
30~1500 |
|
Spindle speed step |
steps |
18steps |
18steps |
|
Spindle travel |
mm |
85 |
70 |
|
Max.swivel angle of vertical milling head |
|
±45° |
±45° |
|
Distance between spindle nose and table surface |
mm |
115/500 |
30/400 |
|
Main motor Power |
kw |
11 |
7.5 |
|
Overall dimensions(L×W×H) |
mm |
2556×2159×2258 |
2300X1770X1900 |
|
Net weight |
kg |
4250 |
2900 |
