Specification |
Unit |
XK5032 |
XK5040 |
|
Table travel of X/Y/Z |
mm |
900x290x270 |
920x350x450 |
|
Table size |
mm |
320x1325 |
400x1700 |
|
Number/width/pitch of T-slot |
mm |
3-18-70 |
3-18-90 |
|
Max. load of table |
kg |
320 |
500 |
|
Distance from spindle nose to table |
mm |
100~370 |
50~500 |
|
Distance from spindle to column |
mm |
350 |
450 |
|
Rapid feed speed of X/Y/Z |
mm/min |
5000/3000/4000 |
5000/3000/4000 |
|
Feed speed of X/Y |
mm/min |
3-3000 |
3-3000 |
|
Spindle travel |
mm |
70 |
85 |
|
Spindle taper |
|
ISO50 (7:24) |
ISO50(7:24) |
|
Max. revolving angle of vertical milling head |
|
±45° |
±45° |
|
Spindle speed range |
r/min |
30-1500 |
30-1500 |
|
Spindle speed step |
steps |
18steps |
18steps |
|
Spindle motor power |
kw |
7.5 |
11 |
|
Longitudinal, transverse feed motor torque |
N.m |
12 |
12 |
|
Vertical feed motor torque |
N.m |
22 |
22 |
|
Max. spindle torque |
N.m |
1000 |
1000 |
|
Overall dimensions(L×W×H) |
mm |
2295x2250x1900 |
2310x2200x2394 |
|
Net weight |
kg |
2800 |
4300 |
